Rated capacity(R.C) |
tf |
1,2,3,5,10,20,50,100tf |
|
Rated output(R.O.) |
mV/V |
2.0 ± 0.005 |
|
Zero balance |
mV/V |
0 ± 0.02 |
|
Accuracy class |
|
H |
G |
|
Combined error |
% |
0.02 |
0.05 |
|
Repeatability |
% |
0.01 |
0.02 |
|
Creep for 30min |
% |
0.03 |
0.03 |
|
Temperature effect on |
|
Zero Value |
%/10℃ |
0.03 |
0.03 |
|
Output Value |
%/10℃ |
0.03 |
0.03 |
|
Excitation |
|
Recommended |
V |
10 |
|
Maximum |
V |
15 |
|
Resistance |
|
Input |
Ω |
400 ± 30 |
|
Output |
Ω |
350 ± 3.5 |
|
Insulation |
MΩ |
> 2000 |
|
Compensated
temperature range |
℃ |
-10to + 40 |
|
Operating
temperature range |
℃ |
-30to + 80 | |
